- Size: 30.3x14.4x12.6
- Place of Origin: China
- Brand Name: Jovision
- Model Number: JVS-N4730SL
- Weight: 1.190 kg
1/2.8" 3.0MP CMOS
3.0MP@30fps
Wide Dynamic Range (WDR)
With Starlight function
Smart IR Range Up to 40m
Low Bitrate, Excellent low light performance
3D DNR
ROI, Defog, HLC, Corridor mode, DIS
EZ-Install Series
- Size: 30.3x14.4x12.6
- Place of Origin: China
- Brand Name: Jovision
- Model Number: JVS-N4730SL
- Weight: 1.190 kg
CAMERA | |
Image Sensor | 1/2.8” Progressive 3.0MP CMOS |
Min. illumination | 0Lux with IR ON |
Day & Night | IR cut filter with auto switch |
Auto Iris | No |
Wide Dynamic Range | WDR |
Digital Noise Reduction | 3D DNR |
Lens | 4/6 mm(F2.0) |
FOV | 4mm: H 79.2°, V 57.2°, D: 103.9° |
IR LED | 4Pcs Array LED |
IR Range | Upto40 m（131ft） |
IMAGE | |
Video Compression | H.264 / H.265 |
Bit Rate (CBR/VBR) | Main stream: 409kbps- 8 Mbps; |
Max Resolution | 2048x1520@30fps |
Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness |
HLC | Support |
9:16 Corridor mode | Support |
DIS | Auto |
ROI | Support |
Defog | Support |
NETWORK | |
Network Protocols: | HTTP, TCP/IP, ICMP, RTSP, RTP, UDP, RTCP, SMTP, DHCP, DNS, CloudSEE. |
Alarm Trigger | Motion Detection |
RTSP Video | Standard RFC2326, Support QuickTime / VLC Player. |
Security | User security authentication, Reset, Hardware Watch Dog |
Web Language | English, Chinese, German |
System Compatibility | ONVIF 2.4 |
Browser | IE8 , Chrome18 ~ 42- |
NTERFACE | |
Ethernet | 1 RJ45 10M / 100M Ethernet |
Audio I/O | 1Ch Audio In |
BNC Output | Not Support |
Reset Button | Not Support |
Edge Storage | Not Support |
General | |
Power Supply | DC12V/2A, PoE IEEE802.3af |
Power Consumption | 3W (During day) ；6.5W（At night with IR） |
Operating Temperature | -20℃ - 60℃ |
Operating Humidity | 0% - 90% Rh Non-Condensation |
Product Dimensions | 300.9x 97.3x 87(mm) |
Product Weight | ≤790(g) |
