VIDEO/AUDIO INPUT

Video Input

4-Ch 1.0MP/ 1.3MP/ 2.0MP/ 3.0MP/ 4.0MP/ 5.0MP

8-Ch 1.0MP/ 1.3MP/ 2.0MP/ 3.0MP/ 4.0MP/ 5.0MP

Incoming Bandwidth

20Mbps

40Mbps

Audio Input

N/A

VIDEO/AUDIO OUTPUT

Recording Resolution

1.0MP/1.3MP/2.0MP/3.0MP/4.0MP/5.0MP

Playback

4-Ch 1.0MP/ 4-Ch 1.3MP/ 4-Ch 2MP/ 3-Ch 3MP/ 2-Ch 4MP/ 2-Ch 5MP

HDMI Output

1-Ch, Resolution:3840×2160@30Hz/ 1920×1080@60Hz / 1920×1080@50Hz/ 1440×900/ 1280×720@50Hz/ 1280×720@60Hz/ 1280×1024/ 1280×800/ 1024×768

VGA Output

1-Ch, Resolution:1920×1080@60Hz/ 1920×1080@50Hz/ 1440×900/ 1280×720@50Hz/ 1280×720@60Hz/ 1280×1024/ 1280×800/ 1024×768

Playback Mode

Time List & Event Playback

Audio Output

1-Ch G.711a / G.711u

HARD DISK

SATA HDD

1 SATA Interface 3.5''

Mounting Mode

Direct plug

Capacity

Up to 6TB

NETWORK

Network Protocols

TCP/IP, UDP/IP, CloudSEE, SMTP, NTP, DHCP

Ethernet

1RJ-45 10/100Mbps self-adaptive Ethernet interface

INTERFACE

HDMI/VGA

1 Port HDMI, 1 Port VGA

USB

2x USB 2.0

Alarm I&O

N / A

Serial Port

N / A

Browser

IE8 , Chrome18 ~ 42-

Security

User security authentication, Reset, Hardware Watch Dog

Web Language

English, German

System Compatibility

ONVIF 2.4

GENERAL

Power Supply

DC12V / 2A

Power Consumption

≤15W（Without HDD）

Operating Temperature

-10°C - 55°C

Operating Humidity

0% - 90% Rh Non-Condensation

Dimensions W×D×H

260×219×45 mm

Weight

≤700g
